24 0716-M001-0
Fig. 2
Traversa
Cross-bar
Traverse
Traverse
Traviesa
Rampe di salita
Approach ramps
Auffahrrampen
Rampes d'accès
Rampas de subida
3
Centrale idraulica
Hydraulic unit
Hydraulikzentrale
Unité de commande
hydraulique
Centralita hidráulica
Quadro elettrico
Control Panel
Schaltkasten
Coffret électrique
Cuadro eléctrico
1
5
2
4
1
5
