65
0716-M001-0
5.5 Identificazione dei comandi e loro funzioni
Con riferimento alla Fig.22:
SALITA
- Interruttore generale (1) in pos. 1.
- premere il pulsante di salita (2) fino al raggiungimento
dell’altezza voluta.
STAZIONAMENTO
- Premere il pulsante giallo (3); la posizione della
piattaforma è stabilizzata automaticamente sui martelletti.
DISCESA
- Premere brevemente il pulsante di salita (2) sollevando
la piattaforma di 30-40 mm per disinserire i martelletti.
- Premere il pulsante di discesa (4).
5.5 Controls
Please refer to Fig.22:
RISE
- Turn main switch (1) to pos. 1.
- Press the up button (2) until raising lift to required height.
HOLD
- Press the yellow button (3). The safety catches will engage
to hold the platform steady.
DESCENT
- Shortly press the up button (2) to lift platform 30-40 mm,
just enough to release catches.
- Press the descent button (4).
5.5 Identifikation der Steuerungen und Funktionen
Unter Bezugnahme auf die Abbildung 22:
HEBEN
- Hauptschalter (1) in Pos. 1.
- die Hebesteuertaste (2) solange drücken, bis man die
gewünschte Höhe erreicht hat.
STILLSTAND
- die gelbe Taste (3) drücken; die Position der Plattform
wird automatisch auf den Klinken stabilisiert.
SENKEN
- die Hebesteuertaste (2) kurz drücken und so die Plattform
30-40 mm anheben, um so die Klinken zu lösen.
- die Senksteuertaste (4) drücken.
5.5 Repérage des commandes et leurs fonctions
Avec référence à la Fig.22:
MONTEE
- interrupteur général (1) en pos. 1.
- appuyer sur le bouton de montée (2) jusqu’à atteindre la
hauteur souhaitée.
STATIONNEMENT
- appuyer sur le bouton jaune (3); la position de la plate-
forme est automatiquement stabilisée sur les taquets.
DESCENTE
- appuyer brièvement le bouton de montée (2) en relevant
la plate-forme de 30-40 mm pour déclencher les taquets.
- appuyer sur le bouton de descente (4).
5.5 Identificación de los mandos y sus funciones
Referencia Fig.22:
SUBIDA
- Interruptor general (1) en pos. 1.
- Presionar el pulsante de subida (2) hasta alcanzar la
altura deseada.
ESTACIONAMIENTO
- Presionar el pulsante amarillo (3); la posición de la
plataforma se estabiliza en forma automática en las
palancas giratorias.
BAJADA
- Presionar brevemente el pulsante de subida (2)
levantando la plataforma de 30-40 mm para desactivar
las palancas giratorias.
- Presionar el pulsante de bajada (4).
