41
0700-M001-0
RISERVATO AL PERSONALE AUTORIZZATO ALL'INSTALLAZIONE - ONLY FOR INSTALLATION-AUTHORIZED STAFF
IST DEM ZUR INSTALLATION AUTORISIERTEN PERSONAL VORBEHALTEN - SEULEMENT POUR LE PERSONNEL AUTORISE A L'INSTALLATION - RESERVADO AL PERSONAL ENCARGADO DE LA INSTALACION
RAV4300-RAV4350-RAV4351
RAV4355-RAV4400-RAV4401
RAV4405-RAV4501-RAV4650-RAV4800
4.5 Allestimento colonna comandi
Con riferimento alla figura 9:
La colonna comandi (1) è riconoscibile per il supporto
centralina.
- Montare la centralina (2) sulla colonna.
- Montare la scatola comandi (3) inserendo le viti di fissaggio
nelle apposite sedi previste sulla colonna (1) e bloccarle.
- Collegare il motore e la relativa sonda termica (vedi
schema elettrico) al cavo di alimentazione (4).
- Collegare il cavo di alimentazione (5) al connettore
elettrovalvola idraulica di discesa (6).
- Fissare la valvola pneumatica (8) al supporto colonna ed
innestare il connettore (9).
4.5 Preparing the control column
With reference to figure 9:
The control column (1) can be recognized by its control unit
mount.
- Fit the control unit (2) onto the column.
- Fit the control box (3) and insert the fastening screws into
their seats into the column (1) and tighten.
- Connect the motor and thermal probe (see wiring diagram)
to the power cable (4).
- Connect the power cable (5) to the hydraulic solenoid
valve for downstroke (6).
- Secure the pneumatic valve (8) to the column support
and connect the connector (9).
4.5 Mise en place colonne de commande
En référence à la figure 9 :
La colonne de commande (1) est reconnaissable par le
support centrale hydraulique.
- Monter la centrale (2) sur la colonne.
- Monter le boîtier de commande (3) en introduisant les vis
de fixation dans les logements appropriés prévus sur la
colonne (1) et les bloquer.
- Raccorder le moteur et la sonde thermique
correspondante (voir schéma électrique) au câble
d’alimentation (4).
- Raccorder le câble d’alimentation (5) au connecteur
électrovanne hydraulique de descente (6).
- Fixer la soupape pneumatique (8) au support colonne et
emboîter le connecteur (9).
- Fixer le fin de course chemins de roulement à hauteur
dangereuse (10).
- Regrouper tous les câbles électriques entre eux au
moyen du collier (11).
- monter le kit (12) de distribution courant électrique + air
comprimé (présent uniquement sur les modèles
RAV4300DC-RAV4350DC-RAV4401DC-
RAV4650DC-
RAV4800DC).
4.5 Ausrüstung der Steuersäule
Mit Bezug auf Abbildung 9:
Die Steuersäule (1) ist aufgrund des Steuergehäuse-
Halters erkennbar.
- Das Steuergehäuse (2) auf die Säule montieren.
- Den Steuerkasten (3) montieren und die
Befestigungsschrauben in die entsprechenden auf der
Säule (1) vorgesehnen Sitze einfügen und anziehen.
- Den Motor und die entsprechende Wärmesonde (siehe
Schaltplan) mit dem Speisekabel (4) verbinden.
- Das Speisekabel (5) mit dem Verbinder des
hydraulischen Senkelektroventils (6) verbinden.
- Das Pneumatikventil (8) am Halter befestigen und den
Verbinder (9) einstecken.
- Den Plattform-Endschalter auf gefährlicher Höhe (10)
fixieren.
- Mit der Schelle (11) alle Elektrokabel miteinander
umbinden.
- das Kit für Strom- (12) + Druckluftverteilung montieren
(nur an den
RAV4300DC-RAV4350DC-RAV4401DC-
RAV4650DC-RAV4800DC-Modellen vorhanden).
4.5 Preparación columna de mandos
Con referencia a la figura 9:
La columna de mandos (1) se reconoce por el soporte de
la centralita.
- Montar la centralita (2) en la columna.
- Montar la caja de mandos (3) introduciendo los tornillos
de fijación en los respectivos alojamientos previstos
sobre la columna (1) y ajustarlos.
- Conectar el motor y la relativa sonda térmica (ver esquema
eléctrico) al cable de alimentación (4).
- Conectar el cable de alimentación (5) al conector de la
electroválvula hidráulica de descenso (6).
- Fijar la válvula neumática (8) al soporte columna e
introducir el conector (9).
- Fijar el final de carrera plataformas a una altura peligrosa
(10).
- Unir todos los cables eléctricos con abrazaderas (11).
- montar el kit (12) de distribución corriente eléctrica + aire
comprimido (presente solo en los modelos
RAV4300DC-
RAV4350DC-RAV4401DC-
RAV4650DC-RAV4800DC).
- Fissare il finecorsa pedane ad altezza pericolosa (10).
- Fascettare tutti i cavi elettrici tra loro tramite la fascetta
(11).
- Montare il kit (12) di distribuzione corrente elettrica + aria
compressa (presente solo sui modelli
RAV4300DC-
RAV4350DC-RAV4401DC-
RAV4650DC-RAV4800DC).
- Secure the limit switch for “boards at dangerous height”
(10).
- Tie all electric cables using the clip (11).
- Install power + compressed air kit (12) (on RAV4300DC-
RAV4350DC-RAV4401DC-RAV4650DC-RAV4800DC
models, only).
