TECHNICAL CHARACTERISTICS
technical characteristics of Chronos, Zeus, Ercole and Ermes chimneys
Ercole Ermes Chronos Zeus U
Ø internal diameter of smoke outlet pipe 148 148 148 148 mm
Ø outer diameter of smoke outlet pipe 148 148 148 148 mm
Max. heating volume 190 215 156 168 m
3
Rated power 8 -9,3 9-10,4 6,5-7,5 7-8,1 kW
Hourly consumption 2,32 2,32 1,96 1,96 kg/h
Loading interval 50 50 50 50 min
Red. - Nom. Yield 86 86 86 86 %
NOx 13% O
2
83 83 105 105 mg/m
3
PM 13% O
2
29 29 19 19 mg/m
3
OGC 13% O
2
65 65 28 28 mg/m
3
CO al 13% di O
2
1096 1096 708 708 mg/m
3
CO al 13% di O
2
0,08 0,08 0,07 0,07 %
Smoke ow 6,9 6,9 5,9 5,9 g/s
Minimum draft 10,0 - 0,1 10,0 - 0,1 10,0 - 0,1 10,0 - 0,1 Pa - mbar
Smoke temperature 187 187 184 184 °C
Energy efficiency class A+ A+ A+ A+ A+
Seasonal space heating energy e󰀩ciency 76 76 76 76 %
Type of room temperature control Single phase heat output without room temperature control
Other control options N/A
The data shown here is provided as a guideline and is not binding, and may change based on what type and quality of wood is used.
Ravelli reserves the right to make any changes in order to improve product performance.
Measurements
Ercole Ermes Chronos Zeus Unit of
measurement
Height 570 570 470 470 mm
Width 688 838 688 838 mm
Depth 623 623 438 438 mm
Empty weight 124 129 113 132 kg
