SHIFT THE POSITION OF THE LINE | CR7/CR12 | QUICK START GUIDE
PAGE 18/35 | User manual | 116-8000-017 | Rev. B2
8 SHIFT THE POSITION OF THE LINE
#
Beschrijving
Afbeelding
46
Two ways to change the line position.
1. Shift with a set distance.
Left or right (example 10cm).
2. Line centering: guidance line will
placed directly underneath the
machine.
47
If you want to change the distance the line
needs to be shifted (example from 10cm to
20cm), press and hold the icon.
48
Now set the desired values and then confirm
with the green check mark.
49
The center of the widget displays the
distance the guidance line has been shifted
from the orginal line.
