Manual # 016-0130-061 Rev A 10/06
7
C HAPTER
S
YSTEM
O
PERATION
Operation of the PowerGlide Autoboom system is very simple. Assuming that the
previous chapters’ instructions were followed and that the Autoboom is installed
and operational, only a few basic operations are necessary for the system.
Enabling
Autoboom
To Enable:
1. Press the Disable/Enable switch for the left and right side individually.
These switches will enable the booms independently, which will allow
an operator to run a boom manually along a fence line, grove, etc. and
allow the opposite boom to be in automatic operation.
2. Tap the down function on the joystick. Holding the down function is
not necessary. If down is held for more than half a second, the boom
will only go down for as long as it was held until the switch was
released.
To Disable (There are TWO ways of disabling PowerGlide Autoboom system):
1. Press the Disable/Enable switch for the left and right side individually.
These switches will disable the booms independently.
OR
2. Press the “Up” functions on the sprayer boom control.
Important: Always have the wheels on the ground when
initially activating the PowerGlide Autoboom system.
