Raven RCM User Manual

016-0171-694 Rev. B 35
SPREADER OPERATION
TABLE 2.
System Settings
ALARM SETTINGS
Press the Alarm Settings tab to modify or update alarm settings such as Off Rate Alarm and the Minimum Flow
Rate. There is also an option to update the Pressure Alarm.
RATES SETUP
The Rates Setup tab allows the user to adjust the Preset Rate Values, Rate Bump, Rate Selection, and other values
that were entered during the original configuration.
FEATURE UNLOCKS
To activate additional features available for the RCM, enter the Activation Key to access these features.
NOTE: Contact a local Raven dealer for additional information regarding available features for your specific
application and for assistance with purchasing activation keys.
TOTALS
The totals button provides options to access a Current Totals, Device totals, and Distance totals tabs.
Button Description
Control Valve Setup
The Control Valve button allows the user to adjust the following settings
for each product:
•Valve Response Rate
•Control Dead Band
•Valve Delay
•Enable PWM Smart Control
Rate Sensor Setup
Allows the operator to modify/edit the calibration value for the encoder
used on the control channel.
Tank Fill Settings
This button allows the user to enter the Tank Capacity, Current Tank Level,
and Low Tank Level.
Display Setup Menu The Display Setup Menu allows the user to configure the main run page.
Pressure Sensor
Setup
This button allows the user to modify the alarm Min and Max for any
products that have pressure alarms selected.
Auxiliary Functions
The Auxiliary Functions button allows the user to create new or modify
existing auxiliary functions such as RPM sensors.
Scale Setup Scale Setup allows the user to configure scale options.
