Raven RCM User Manual

016-0171-694 Rev. B 41
STAND-ALONE SCALE OPERATION
MAIN
Press main at any time to return to the current product run page.
SETUP
Pressing setup opens a page with many tabs.
FIGURE 7. Setup Tabs
APPLICATOR SETUP TAB
The Applicator Setup Tab provides options to create a new, edit, or remove an applicator. This tab also provides a
summary to the section configuration.
SYSTEM SETTINGS
The Systems Settings Tab allows the user to modify the current scale calibration.
FEATURE UNLOCKS
To activate additional features available for the RCM, enter the Activation Key to access these features.
NOTE: Contact a local Raven dealer for additional information regarding available features for your specific
application and for assistance with purchasing activation keys.
TOTALS
The totals button provides options to access a Current Totals, Device totals, and Distance totals tabs.
Applicator
Setup
System
Setting
Feature
Unlocks
