Raven SCS 5000 Series User Manual

Manual No. 016-0159-925 Rev. F 7
Introduction
Care and Use
Refer to the following guidelines for proper care and use of the SCS console.
• Mount the console securely and route cables to prevent tripping hazards and to keep the wires from
pinching or breaking.
• When temperatures are expected to be 10° F [-12° C] or lower, remove the console from the vehicle and
store it in a climate controlled environment.
• Do not expose the console to precipitation, condensation or other liquids. Store the console in a dry
environment when not in use.
• To prevent damaging the console, be sure to disconnect the console’s power connection when jump
starting or welding on the machine.
Technical Specifications
CAUTION
U.S. Metric
Dimensions
Height 8.007 in. 20.338 cm
Width 8.991 in. 22.837 cm
Depth
2.995 in.
(Enclosure Only)
7.607 cm
(Enclosure Only)
Weight
5.5 lbs. (max.) 2.5 kg (max.)
Environmental
Operating
Temperature
-4° F to 158° F -20° C to 70° C
Storage
Temperature
-40° F to 185° F -40° C to 85° C
Power
Operating
Voltage
9 VDC to 16 VDC
Reverse Polarity Protected
Ports
Amp 1 (Back)
Card Slot -
Compact Flash
(SCS 4400/4600 Only)
1 (Side Cover)
Mounting
Clamp
a
(Provided)
a.Designed to secure the SCS 4000/5000 Series Console to a 1” dia. [2.54 cm]
monitor bar or post.
1.020 in. dia. 2.59 cm dia.
Thumb Screws
(Provided)
1/4”-20 x 1” Long
