Charging
Ray
For best long term results always start with a fully charged Ray.
x Turn the Power Switch to OFF.
x Connect Ray to the AC Adapter.
x Plug the AC adapter into an electric outlet.
x When the Power Light flashes once per second the Ray is being
charged.
x Ray’s dead battery will be fully charged in 12 hours.
x The Power Light stops flashing when Ray’s battery is fully charged.
Steady power light glow indicates a fully charged Ray.
Caution:
Only use the AC Adapter supplied with Ray.
8
Specifications
Display Technology LCoS Technology
Light Source LED
Resolution VGA 640 x 480
Brightness( Typical) 8-10 Lumens
Frame Rate 60Hz
Color 24-bit RGB
Image Size (Diagonal) 5” at 8” / 73” at 9½’
Projection Distance 8” to infinite
Uniformity 90%
Focus Manual Focus
I/O Connection TV Composite Video
Speaker Mono
Weight 5 oz
Dimensions (W x D x H) 2¹/3” x 4½” x 3½”
60 x 113 x 18 mm
Power Supply Rechargeable Li-ion Battery
Battery Life Greater then 2 hours
