User Guide of RFL-C3300W~RFL-C15000W
11
Figure 3-a Front and rear view of the laser
Figure 3-b Top and left view of the laser.
Figure 3 The dimensions of RFL-C12000X continuous wave fiber laser.
The RFL-C10000X / C12000X two lasers share a set of cabinets.
Model
RFL-C10000X
RFL-12000X
N.W
450kg
500kg
Dimensions
1200*960*1160mm(L×W×H)
(4) The external dimensions of the RFL-C15000W continuous fiber laser are
shown in Figure 4.
