RFL-P100QA Pulsed Fiber Laser User’s Guide V2.1
2
if laser is mounted in a cabinet with fans, the direction should be same as laser’s fans.
g) Do not look into the output head of the device directly. Please do wear appropriate laser
safety eyewear during the time when operating the device.
h) Make sure the pulse repetition rate higher than 80 kHz.
i) For the longest time without pulse is only 100 us. If there is no pulse output, please stop
marking at once, to avoid further damage of the device.
j) Power source sudden interruption will do great harm to the laser device. Please make sure
the power supply works continuously.
1.4. Specifications
Table 2 100QA pulsed fiber laser specifications
Pulsed fiber laser
100QA
Wavelength（nm）
1060~1085
Polarization
Random
Optical isolator
Yes
Nominal average output power (W)
≥100
Single pulse energy (mJ)
1.25@80 kHz
Beam quality
（
M2
）
<1.6
Beam diameter（mm）
5.5～8
Pulse duration（ns）
250-290@80 kHz
Pulse repetition rate
（
kHz
）
80-120
Output power tunability（%）
10-100
Output fiber cable length
（
m
）
3.0
Working voltage（VDC）
24±1
Power consumption（20℃）（W）
380
Cooling
Forced Air Cooled
Dimension W×H×D（mm）
310×116.5×260
Operating temperature
（
℃
）
0℃
～
40℃
Store temperature（℃）
-20℃～60℃
Operating humidity
（
%
）
≤80
