20QS/30QS Pulsed Fiber Laser User’s Guide V1
2
f) The device has three cooling fans at the rear panel to dissipate heat. In order to
guarantee enough airflow to help giving heat off, there must be a space of at least
10cm’s width for airflow in front and rear side of the device. As the cooling fans are
working at blow condition, if laser is mounted in a cabinet with fans, the direction
should be same as laser’s fans.
g) Do not look into the output head of the device directly. Please do wear appropriate
laser safety eyewear during the time when operating the device.
h) Make sure the pulse repetition rate higher than 30 KHz.
i) For the longest time without pulse is only 100 us. If there is no pulse output, please
stopmarking at once, to avoid further damage of the device.
j) Power source sudden interruption will do great harm to the laser device. Please make
sure the power supply works continuously.
1.4. Specifications
Table 2. 20QS、30QS pulsed fiber laser specifications
Pulsed fiber laser
20QS
30QS
Wavelength（nm）
1060~1085
1060~1085
Polarization
Random
Random
Optical isolator
Yes
Yes
Nominal average output power (W)
≥20
≥30
Single pulse energy (mJ)
0.66@30kHZ
0.75@40kHZ
Beam quality（M2）
<1.6
<1.6
Beam Diameter（mm）
6～8
6～8
Pulse duration（ns）
120-150@30kHZ
130-160@40kHZ
Pulse repetition rate（kHz）
30-60
40-60
Output Power Tunability（%）
10-100
10-100
Output Fiber Cable length（m）
3.0
3.0
Working voltage（VDC）
24±1
24±1
Power consumption（20℃）（W）
150
200
Cooling
Forced Air Cooled
Forced Air Cooled
Dimension W×D×H（mm）
290*215*95
290*215*95
Operating temperature（℃）
0℃～40℃
0℃～40℃
Store temperature（℃）
-10℃～60℃
-10℃～60℃
humidity（%）
30%~85%
30%~85%
