User’s guide Ytterbium Pulsed Fiber Laser RFL-P10Q/P20Q/ P30Q/ P20QE/P50QB Ver.: 2.0
3 / 9
2. Mounting
2.1 Mounting dimensions
1) Fiber Laser module dimensions (As shown in Fig. 1).
Figure 1. Dimension drawing of laser module (Unit: mm).
2) Isolated output head dimensions (As shown in Fig. 2).
Figure 2. Dimension drawing of output isolator (Unit: mm).
2.2 Method of installation
1) Fix the module stable to the bracket and keep the laser in good ventilation.
2) Connect the power line to 24VDC power and ensure enough DC output power. Keep it clear
