Changingtheradarvesseloffset

RadaroffsetisonlyavailableinRelativemotion

mode.

Fromtheradarapplication:

1.SelectMenu.

2.SelectPresentation.

3.SelectOrientation&MotionMode.

4.SelectBoatOffset.

5.Selecttherequiredoffsetvalue.

Radarapplication

243
