Raymarine axiom pro 12 RVX

Questions and Answers

B
Barbara DuarteAug 8, 2025
How to fix Wi-Fi issues on Raymarine axiom pro 12 RVX Marine GPS System?
- A
  Alyssa ThomasAug 9, 2025
  Having trouble with Wi-Fi on your Raymarine Marine GPS System? Here's what to check: * **Wi-Fi not enabled:** Make sure Wi-Fi is enabled on both devices and rescan for available networks. * **Wi-Fi automatically turning off:** Power cycle/reboot devices and rescan for available networks, as some devices may turn off Wi-Fi to save power. * **Device not broadcasting:** Try enabling broadcasting of the device’s network in the Wi-Fi settings. If that doesn't work, manually enter the device’s Wi-Fi Name/SSID and passphrase in the connection settings. * **Devices out of range/signal blocked:** Move devices closer together or remove obstructions and rescan for available networks.
N
Natalie ShepherdAug 13, 2025
What to do if Raymarine Marine GPS System display is behaving erratically?
- S
  Scott FergusonAug 13, 2025
  If your Raymarine Marine GPS System display is behaving erratically, try the following: * **Check fuses and breakers:** Inspect the relevant fuses and breakers. * **Inspect power supply cable:** Check the power supply cable for any damage and ensure all connections are tight and free from corrosion. * **Verify power source:** Ensure the power source provides the correct voltage and sufficient current. * **Software update:** Check for software updates on the Raymarine website. * **Factory reset:** As a last resort, perform a factory reset. Note: This will erase all settings and data stored on the product, so save any important data beforehand.
K
Karen JacksonAug 17, 2025
Why is my Raymarine axiom pro 12 RVX connection so slow?
- A
  allison84Aug 17, 2025
  If your Raymarine Marine GPS System connection is slow or keeps dropping, consider the following: * **Distance:** Move devices closer together, as Wi-Fi performance degrades over distance. For fixed installations like a Quantum Radar, enable the Wi-Fi connection on an MFD closer to the device. * **Interference:** Change the Wi-Fi Channel of the device you are trying to connect to and retry the connection. Temporarily switch off each device in turn until you have identified the device causing the interference.
A
Amy SmithAug 27, 2025
What causes no depth reading on my Raymarine axiom pro 12 RVX Marine GPS System?
- D
  Denise GrantAug 27, 2025
  If your Raymarine Marine GPS System shows no depth reading or has lost bottom lock, check these potential issues: * **Transducer location:** Ensure the transducer is installed according to its instructions. * **Transducer angle:** Adjust the transducer angle if it's too great, as the beam might be missing the bottom. * **Transducer kicked-up:** If the transducer has a kick-up mechanism, ensure it hasn't kicked up due to hitting an object. * **Insufficient power source:** Check the power supply voltage as close to the unit as possible under load. * **Damaged or fouled transducer:** Check the transducer for damage and ensure it's free from debris/fouling.
W
Wesley BaileyAug 30, 2025
What to do if Raymarine axiom pro 12 RVX Marine GPS System displays 'No Fix' GNSS status?
- L
  Louis FrancoAug 30, 2025
  If the “No Fix” GNSS status icon is displayed on your Raymarine Marine GPS System, consider the following: * **Geographic location or conditions:** Check periodically to see if a fix is obtained in better conditions or another geographic location. * **GNSS connection fault:** Ensure that external GNSS connections and cabling are correct and fault free. * **External GNSS receiver location:** Ensure the GNSS receiver has a clear view of the sky. * **GNSS installation problem:** Refer to the installation instructions.
T
Tina WilkersonNov 3, 2025
How to troubleshoot a Raymarine axiom pro 12 RVX Marine GPS System that won't turn on?
- A
  Ann EllisonNov 4, 2025
  If your Raymarine Marine GPS System isn't turning on or keeps turning off, there are several potential causes: * **Blown fuse/tripped breaker:** Check the condition of the fuses and breakers, replacing them if necessary. If the fuse keeps blowing, inspect for cable damage, broken connector pins, or incorrect wiring. * **Poor power supply cable/connections:** Ensure the power cable connector is fully inserted and locked. Look for damage or corrosion on the cable and connectors, replacing if needed. Flex the power cable near the display connector to see if it causes the unit to restart or lose power. Also, check the vessel's battery voltage and the condition of the battery terminals and power supply cables, ensuring they are secure, clean, and free from corrosion. * **Incorrect power ...
B
breannahuberNov 21, 2025
Why is scrolling image not being displayed on Raymarine Marine GPS System?
- A
  Antonio CollinsNov 21, 2025
  If the scrolling image isn't being displayed on your Raymarine Marine GPS System, here's what you can check: * **Sonar disabled:** Ensure 'Ping Enable' is selected in the Sonar app's Sounder menu. * **Incorrect transducer selected:** Verify the correct transducer is selected in the Sonar app's Transducer menu. * **Damaged cables:** Check the transducer cable connector is fully inserted and locked. Inspect the power supply cable and connectors for damage or corrosion. Flex the cable near the display connector to check for loose connections. Also, check the vessel's battery voltage, the condition of the battery terminals, and power supply cables. * **Damaged or fouled transducer:** Check the transducer's condition, ensuring it's not damaged and free from debris/fouling. * **Wrong ...

Summary

Chapter 1: Important Information

Chapter 2: Document and Product Information

Compatible Transducers

Information on transducers compatible with Axiom Pro MFDs, including RealVision and DownVision types.

Chapter 3: Installation

Selecting a Location

Guidance on choosing a suitable installation location, considering ventilation, mounting, and interference.

Mounting Options

Overview of surface mounting and bracket (trunnion) mounting options for Axiom Pro units.

Surface Mounting

Step-by-step instructions for surface mounting the MFD, including template use and connection.

Bracket (Trunnion) Mounting

Instructions for mounting the MFD using the supplied trunnion bracket on a horizontal surface.

Chapter 4: Connections

Power Connection

Details on connecting the power cable to a 12/24V DC supply, including fuse and breaker ratings.

Transducer Connection

Information on connecting RealVision 3D, 1kW, and CPT-S transducers to Axiom Pro MFDs.

Network Connection

Instructions for connecting the MFD to other RayNet devices or a network switch.

Chapter 5: Maintaining Your Display

Service and Maintenance

Information on product service, warnings, and routine equipment checks.

Chapter 6: Troubleshooting

Touchscreen Troubleshooting

Chapter 7: Technical Support

Chapter 8: Technical Specification

Axiom Pro Technical Specification

Detailed technical specifications for Axiom Pro MFDs, including power, environmental, LCD, and connections.

Chapter 3: Set Up

Getting Started

Initial setup steps for the MFD, including data master selection and startup wizard.

Software Updates

Chapter 4: Homescreen

Homescreen Overview

Settings

Overview of the Settings menu tabs: Getting started, Boat details, Units, This display, Autopilot, Network.

Satellite Navigation; Positioning

Chapter 5: Autopilot Control

Autopilot Control

How to enable, disable, and engage the autopilot system via the MFD.

Autopilot Control - Advanced Settings

Chapter 8: Chart App

Chart App Overview

Description of the Chart app's functions, including waypoints, tracks, routes, and data indicators.

Navigation

Instructions for navigating to waypoints, following routes, and restarting cross track error.

Target Tracking

Chart Settings Menu

Chapter 11: Dashboard App

Dashboard App Overview

Chapter 14: Mobile App Support

Raymarine Mobile Apps

Connecting a Mobile Device to your MFD

Step-by-step guide to connecting a mobile device to the MFD via Wi-Fi.

Controlling your MFD using RayControl

Controlling your MFD using RayRemote

Viewing your MFD Screen using RayView

Chapter 15: Troubleshooting

Troubleshooting

General information on diagnosing and correcting common installation and operation problems.

Power Up Troubleshooting

Solutions for issues related to the product not turning on or getting stuck in a restart loop.

Radar Troubleshooting

GNSS Troubleshooting

Sonar Troubleshooting

Camera Troubleshooting

Wi-Fi Troubleshooting

Chapter 16: Technical Support

Raymarine Product Support and Servicing

Information on accessing Raymarine's support services, including website, telephone, and email.

Raymarine axiom pro 12 RVX Specifications

General

Touchscreen	Yes
Sonar	Yes
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Video Input	Yes
Operating Temperature	-15°C to 55°C
Waterproof Rating	IPX6
Operating System	LightHouse 3
Power Supply	10-32 VDC
Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Display Type	IPS LCD
GPS	Yes
Mounting	Flush or bracket
Radar Compatibility	Yes
Networking	RayNet, NMEA 2000
