Raymarine e127 User Manual

GeodeticDatumWGS-84(alternativesavailable
throughRaymarineMFD)
RefreshRate10Hz(10timespersecondConcurrent
GNSS)
Antenna
•Internal—Ceramicchipmounted
neartopofunit
•External—GA150external
antennamaybeused
PositionAccuracy
•WithoutSBAS:<=15metres95%
ofthetime
•WithSBAS:<=5metres95%ofthe
time
Note:*Supportedbutnotcurrentlyavailable.A
softwareupdatewillberequiredtoaddsupportfor
thisGNSSwhenitbecomesavailable.AGA150
mustbeconnectedtoreceiveBeidou.Please
checkwithyourRaymarinedealerforfurther
details.
Internalsonarspecication
Theinternalsonarspecicationsonlyapplytosonar
variantmultifunctiondisplayvariants.
Operatingfrequencies50/83/200KHz
Transmitpower
Upto600WRMS,depending
ontransducer
Depthrange
Upto3000ft,dependingon
transducer
Sonar/DownVision
™
specication
Thefollowingspecicationonlyappliesto
DownVision
™
products.
Channels2xCHIRP(1xsonarand1xDownVision
™
)
Beam
coverage
•Sonar—conicalbeam.
•DownVision
™
—Wide(port/starboard)
andthin(fore/aft)fanbeam.
Depth
Typicaldepthperformanceof183m
(600ft).AppliestobothSonarand
DownVision
™
channels.
a9xanda12xVideospecication
SignaltypeComposite
Format
PALorNTSC
ConnectortypeBNC(female)
Outputresolution
720p
Internalstorage
Multifunctiondisplays(MFDs)includeinternal
storagethatcanbeusedtostorerecordedvideo
andphotostakenusingtheCameraapplication.The
tablebelowshowstheapproximateavailableinternal
storagespaceforLightHousepoweredMFDs.
MFDvariant
Approximate
availableinternal
storage
Approximate
recordtime
(CAM200IP)
aSeries2GB
88.8minutes
cSeries2GB
88.8minutes
eSeries
(excludinge165)
2GB
88.8minutes
e165
6GB
266.6minutes
gSSeries14GB
622.2minutes
Note:
•Theavailableinternalstoragestatedaboveis
basedonMFDmanufacturedafterMay2014.
Availablestorageondisplaysmanufactured
priortothisdatemayvary.
•Availableinternalstoragespaceissubjectto
changewithoutpriornotice.
•Theapproximaterecordtimesstatedabove
weretakenusingaCAM200IPsettoitsdefault
resolutionof720p.Increasingimageresolution
andotherfactorssuchaslightingconditions
mayaffecttheresultinglesizeandtherefor
reducetheavailablerecordtime.
Electronicchartspecication
Embeddedelectronic
charts
•LightHouseChartsworldbase
map.
•Navionicsworldbasemap.
Compatible
LightHousecharts
•Vector—LightHousecharts
•Raster—LightHousecharts
Compatible
Navionicschart
cards
•NavionicsReadytoNavigate
•NavionicsSilver
•NavionicsGold
•NavionicsGold+
•NavionicsPlatinum
•NavionicsPlatinum+
•NavionicsFish'NChip
•NavionicsHotmaps
Note:
RefertotheRaymarinewebsite(www.rayma-
rine.com)forthelatestlistofsupportedcharts.
Technicalspecication
427

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
