Raymarine e7 Mounting And Getting Started

ItemDeviceTypeMaximumquantitySuitableDevicesConnections
13Transducersandsensors—
Raymarine
1Analogtransducers:
•Wind.
•Speed.
•Depth.
SeaTalk
ng
(viaoptionaltransducerpods).
13Transducersandsensors—Airmar1
•DT800SmartSensor.
•DST800SmartSensor.
•PB200weatherstation.
SeaTalk
ng
(viaoptionaltransducerpods).
14Videoout
e95/e97/e125/e127=1
Externaldisplay.
Component
15
Sonartransducer
1
Directconnectiontodisplay(Sonarvariantdisplaysonly):
•RaymarineP48.
•RaymarineP58.
•RaymarineP74.
•RaymarineB6020º
•RaymarineB6012º
•RaymarineB744V
;OR:
•Any600watt/1Kwcompatibletransducer(viaoptional
E66066adaptorcable).
;OR:
•AnyMinnKotatransducer(viaoptionalA62363adaptor
cable).
ConnectionviaexternalRaymarineSonarModule:
•Anysonarmodule-compatibletransducer.
Raymarinetransducerconnection,ORMinnKota
transducerconnection.
16VHFradio—Raymarine1
AllRaymarineDSCVHFradios.NMEA0183only(NoSeaTalksupport).
11

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
