Raymarine e7 Mounting And Getting Started

4.Ensurethebezeliscorrectlyalignedwiththedisplay,
asshown.
5.Applyrmbutevenpressuretothebezelalongthe:
i.Outeredges-workfromthesidesupwardsand
thenalongthetopedge,toensurethatitclips
securelyintoposition.
ii.Inneredges-particularlyalongthechartcard
dooredge,toensurethatthebezelsitsat.
6.Checkthatallcontrolbuttonsarefreetooperate.
Removingthefrontbezel
Beforeproceedingensurethememorycardslotdoor
isopen.
D12 275 -1
2
1
2
1
Important:Usecarewhenremovingthebezel.Do
notuseanytoolstoleverthebezel;doingsomay
causedamage.
1.Placebothyourthumbsontheupperleftedgeof
thedisplay,atthepositionsindicatedinthediagram
above.
2.Placeyourngersunderneaththebezel,atthe
positionsindicatedinthediagramabove.
3.Inasinglermmotion,applypressuretotheouter
edgeofthedisplaywithyourthumbsandpullthe
bezeltowardsyouusingyourngers.
Thebezelshouldnowcomeawayfromthedisplay
easily.
17

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
