Pages
Pagesareusedtodisplayapplications.
Pagesaredisplayedandaccessedonthehomescreen.
Eachpagecandisplayupto4applications(depending
onmultifunctiondisplayvariant).
Note:Thee7ande7Dcanonlycongureupto2
applicationsperpage.Thee7/e7Dcanonlydisplay
4applicationsperpageifconnectedandtoae9/c9
ore12/c12whichhasbeenconguredtoshow4
applicationsperpage..
Anypageonthehomescreencanbecustomized,
enablingyoutogroupyourapplicationsintodifferent
pages,eachdesignedforaspecicpurpose.For
example,youcouldhaveapagethatincludesthe
chartandshnderapplications,suitableforshing,
andanotherpagethatincludesthechartanddata
applications,whichwouldbesuitableforgeneralsailing.
Youcanaddanyapplication(s)
toanyemptypage.
Pagefeaturingasingle
application.
Pagefeaturingmultiple
applications.
Youcanalsodenea"layout"foreachpage,which
determineshowtheapplicationsarearrangedonthe
screen.
Changinganexistingpageonthehomescreen
Withthehomescreendisplayed:
1.SelectCustomize.
2.SelectHomescreen.
3.SelectEditPage.
4.Selectthepageiconthatyouwanttochange.
TheCustomizemenuoptionsaredisplayed.
5.Selecttheappropriatepagelayout(forexample,
“Splitscreen”).
6.Selecttheapplication(s)youwanttodisplayonthe
page,eitherbyselectingtherelevantmenuitemor
draggingitovertothedisplayedpage.
7.SelectFinish.
TheRenamePagedialogisdisplayed.
8.Usetheon-screenkeyboardtonamethepage,then
selectSave.
e7/e7DControls
D12 179 -1
2
4
5
6
7
3
1
1.Touchscreen—youcantouchthescreento
operatemanycommonfunctions,includingall
menuoperations(HybridTouchmultifunction
displaysonly).
2.Menu—accessesmenus.Pressagaintoclose
menus.
3.UniControl—providesajoystickandrotarycontrol
andanOKbuttonforusingmenusandapplications.
4.Back—presstoreturntoapreviousmenuor
dialoglevel.
5.WPT/MOB—pressandreleasetoaccessthe
waypointoptions.Pressagaintoplaceawaypoint.
PressandholdtoplaceaManOverboard(MOB)
markeratyourcurrentposition.
6.Power—pressoncetoswitchtheunitON.Once
poweredon,pressthePowerbuttonagainto
adjustthebrightness,accessthepowercontrolsfor
externaldevices,andaccesstheautopilotcontrols.
PressandholdtoswitchtheunitOFF.
7.Chartcardslots—openthecarddoortoinsert
orremoveMicroSDcards.Thereare2cardslots
(labelled1and2),usedforelectronicchartsand
archivingwaypoint,routeandtrackdata.
22
e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
