Caution:Careofchartand
memorycards
Toavoidirreparabledamagetoand/or
lossofdatafromchartandmemorycards:
•Ensurethatchartandmemorycardsare
ttedthecorrectwayaround.DONOT
trytoforceacardintoposition.
•DONOTsavedata(waypoints,routes,
andsoon)toachartcard,asthecharts
maybeoverwritten.
•DONOTuseametallicinstrumentsuch
asascrewdriverorplierstoinsertor
removeachartormemorycard.
•Saferemoval.Alwayspowertheunitoff
beforeinsertingorremovingachartor
memorycard.
Caution:Ensurechartcard
doorissecurelyclosed
Topreventwateringressandconsequent
damagetothedisplay,ensurethatthe
chartcarddoorisrmlyclosed.Thiscan
beconrmedbyanaudibleclick.
Caution:Cleaning
Whencleaningthisproduct:
•DoNOTwipethedisplayscreenwith
adrycloth,asthiscouldscratchthe
screencoating.
•DoNOTuseabrasive,oracidor
ammoniabasedproducts.
•DoNOTuseajetwash.
TFTDisplays
Thecolorsofthedisplaymayseemtovarywhen
viewedagainstacoloredbackgroundorincoloredlight.
Thisisaperfectlynormaleffectthatcanbeseenwith
allcolorThinFilmTransistor(TFT)displays.
Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthis
productmeetstheIPX6standard,waterintrusionand
subsequentequipmentfailuremayoccuriftheproduct
issubjectedtocommercialhigh-pressurewashing.
Raymarinewillnotwarrantproductssubjectedto
high-pressurewashing.
Disclaimers
Thisproduct(includingtheelectroniccharts)isintended
tobeusedonlyasanaidtonavigation.Itisdesignedto
facilitateuseofofcialgovernmentcharts,notreplace
them.Onlyofcialgovernmentchartsandnoticesto
marinerscontainallthecurrentinformationneeded
forsafenavigation,andthecaptainisresponsiblefor
theirprudentuse.Itistheuser’sresponsibilitytouse
ofcialgovernmentcharts,noticestomariners,caution
andpropernavigationalskillwhenoperatingthisor
anyotherRaymarineproduct.Thisproductsupports
electronicchartsprovidedbythirdpartydatasuppliers
whichmaybeembeddedorstoredonmemorycard.
Useofsuchchartsissubjecttothesupplier’sEnd-User
LicenceAgreementincludedinthedocumentation
forthisproductorsuppliedwiththememorycard(as
applicable).
Raymarinedoesnotwarrantthatthisproductis
error-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthan
Raymarine.
Thisproductusesdigitalchartdata,andelectronic
informationfromtheGlobalPositioningSystem(GPS)
whichmaycontainerrors.Raymarinedoesnotwarrant
theaccuracyofsuchinformationandyouareadvised
thaterrorsinsuchinformationmaycausetheproductto
malfunction.Raymarineisnotresponsiblefordamages
orinjuriescausedbyyouruseorinabilitytousethe
product,bytheinteractionoftheproductwithproducts
manufacturedbyothers,orbyerrorsinchartdataor
informationutilizedbytheproductandsuppliedbythird
parties.
Chartcardsandmemorycards
Memorycardsareusedforarchivingdataandchart
cardsprovideadditionalorupgradedcharts.
Compatiblecards
Thefollowingtypesofmemoryorchartcardare
compatiblewithyourRaymarineproduct:
•microSecureDigitalStandard-Capacity(microSDSC)
•microSecureDigitalHigh-Capacity(microSDHC)
Note:Themaximumcardcapacitysupportedis32
GB.
Chartcards
Yourproductispre-loadedwithelectroniccharts
(worldwidebasemap).Ifyouwishtousedifferentchart
data,youcaninsertcompatiblechartcardsintothe
unit’scardslot.
Usebrandedchartcardsandmemorycards
Whenarchivingdata,Raymarinerecommendstheuse
ofqualitybrandedmemorycards.Somebrandsof
memorycardmaynotworkinyourunit.Pleasecontact
customersupportforalistofrecommendedcards.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformto
theappropriateElectromagneticCompatibility(EMC)
regulations,tominimizeelectromagneticinterference
betweenequipmentandminimizetheeffectsuch
interferencecouldhaveontheperformanceofyour
system
CorrectinstallationisrequiredtoensurethatEMC
performanceisnotcompromised.
ForoptimumEMCperformancewerecommendthat
whereverpossible:
•Raymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmitting
orcablescarryingradiosignalse.g.VHFradios,
cablesandantennas.InthecaseofSSBradios,
thedistanceshouldbeincreasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.
Aradarbeamcannormallybeassumedtospread
20degreesaboveandbelowtheradiatingelement.
4
e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
