4.3NMEA2000(Sea

Talkng®)connection

TheMFDcantransmitandreceivedatafromdevicesconnectedonacompliantCANbusnetwork

thattheMFDisalsoconnectedto.TheMFDisconnectedtothebackboneusingtheDeviceNet

connectoronthePower/NMEA2000cable.

1.P ower/NMEA2000cableconnectstotherearoftheMFD.

2.DeviceNet(Micro-C5pinmale)connectorconnectstoNMEA2000networkorSeaTalkng®via

adaptorcable.

3.DeviceNet(5pinfemale)connector.

4.AdaptorcableconnectstoSeaTalkng®backboneorDeviceNetspurcableconnectstoNMEA

2000network.Availablecables

•A06045—FemaleDeviceNettoSea Talkng®cable,shown.

•E05026—FemaleDeviceNettobareendwires.

Note:

1.Sea Talkng®andNMEA2000devicesmustbeconnectedtoacorrectlyterminatedbackbone

thattheMFDisalsoconnectedto.DevicescannotbeconnecteddirectlytotheMFD.

2.RefertotheinstructionssuppliedwithyourSeaTalkng®/NMEA2000devicefordetailson

creatingabackbone.

4.4T ransducerconnection

IfyourMFDincludesabuilt-insonarmodulethenyoucanconnectatransducertoyourMFD.

Note:

R ealVision™transducersconnectdirectly,allothertransducertyperequireanadaptorcable.

Connections45
