Chapter 5: Digital Selective Calling (DSC) 59
5.2 Distress Calls
For a Distress Call transmission, the Ray49 takes the position and time
information from the input NMEA data along with your MMSI and converts it into
a digital “packet”. When transmitted, this digital information lets other ships and
shore stations equipped with appropriate DSC equipment know where you are
and that you are in a Distress situation.
Your call can specify the nature of the Distress (designated call) or not
(undesignated call).
Sending a Distress Call
Lift the spring-loaded door on the front panel of the transceiver.
Undesignated (Quick) Distress Call
To send a distress call without specifying its nature:
• Press and hold the red
DISTRESS key for 3 seconds to initiate the call. During
this time, the radio beeps, the display flashes and a timer counts down
03...02...01.
D10166-1
D10168-1
PRESS and HOLD for 3 SECS
10
15
20
25
30
35
40
45
50
55
60
5
DISTRES CALL
COUNTING
DOWN...
DISTRES CALL
COUNTING
DOWN...
DISTRES CALL
COUNTING
DOWN...
DISTRES CALL
TRANSMITTING
DISTRESS
UNDESIGNATED
