Welcome to the Raymarine S1000 Autopilot
Congratulations on having bought a Raymarine S1000 Autopilot. This state-of-the-art
product is specifically designed to be easily integrated with your boat’s steering system, and
enable you to automatically control the steering.
The S1000 Autopilot is intended for use in:
• HC5345, HC5347, HC5348, and HC5358 SeaStar steering systems.
• Systems with HC4600, HC4645, HC4647, HC4648, and HC4658, BayStar steering rams.
• Systems with Hynautic K6 steering rams.
SeaTalk
®
is a Registered Trademark of Raymarine
SeaStar
®
is a Registered Trademark of Teleflex Incorporated
BayStar is a Trademark of Teleflex Incorporated
NMEA
®
is a Registered Trademark of the National Marine Electronics Assocociation
All other trademarks used in this document are acknowledged.
© Copyright Raymarine UK Limited 2005
Existing hydraulic steering system
Safety
alarm
Pump control
S1000 Autopilot System
S100 Remote
Course
computer
Autopilot
pump
D7501-1
S100 REMOTE
MODE
STANDBY
PILOT
GPS input
The S1000 requires
GPS data (SeaTalk or
NMEA compatible),
to operate correctly
Alarm signal
