Raymarine SmartPilot S1000 Installation Guide

S1000 Autopilot Installation Guide 3
What you need
Elbow fitting, x 4
'T' fitting x 2
High pressure
steering hoses
(x 2)
Low pressure
transparent
bleeding hose
Straight fitting x 2
Nitrile gloves
Autopilot Pump
Anti-vibration mounts x 2
Course Computer
Wrench 12 mm AF x 19 mm AF
In-line power
switch
Drill 3.4 mm
Miscellaneous
cable ties
D7330-2
S100 Remote & 2 x cradles
1 pint (0.5 liter)
hydraulic fluid
Belt clip assembly
Fill cups
Safety alarm
Parts supplied
S100 REMOTE
MODE
STANDBY
PILOT
Data cable
Power cable
Drain cups
Lanyard
Connector block
Ferrite
