GASKET INSTALLATION - ALL MODELS (Continued)
3. Remove the backing on the new gasket (Fig. 18) and
install as per Fig. 19.
Peel
adhesive
backing.
Fig. 18
When the gasket is installed correctly,there will be
a small part of the bezel showing within the display
window area. The other side of the gasket will be
even with the bezel display window edge.
Fig. 19
