Monitor Menu
The Monitor Menu records and displays critical Boiler information, such as, Cycle times, Run times, and
M
aximum/Minimum temperature readings depending on the setup.
Table R: Monitor Menu
Item Application Description
RUN TIME Burner 1 All Burner run time (hours). Press UP/DOWN for 1 sec to clear.
Cycles Burner All Number of burner cycles. Press UP/DOWN for 1 sec to clear.
RUN TIME Boiler pump All
Boiler pump run time (hours). Press UP/DOWN for 1 sec to
clear.
RUN TIME System pump All
System pump run time (hours). Press UP/DOWN for 1 sec to
clear.
RUN TIME DHW pump
H MODE 2,3
DHW pump run time (hours). Press UP/DOWN for 1 sec to clear.
OUTLET HI All
Records the highest boiler outlet temperature. Press UP/DOWN
for 1 sec to clear.
OUTLET LO All
Records the lowest boiler outlet temperature. Press UP/DOWN
for 1 sec to clear.
INLET HI All
Records the highest boiler inlet temperature. Press UP/DOWN
for 1 sec to clear.
INLET LO All
Records the lowest boiler outlet temperature. Press UP/DOWN
for 1 sec to clear.
DELTA T
All
Captures the highest Delta T temperature recorded Press UP &
DOWN buttons for 3 sec to clear this entry.
OUTDOOR HI
H MODE 1,2,3
Records the highest outdoor temperature. Press UP/DOWN for 1
sec to clear.
OUTDOOR LO
H MODE 1,2,3
Records the lowest outdoor temperature. Press UP/DOWN for 1
sec to clear.
SYSTEM HI All
Records the highest supply temperature. Press UP/DOWN for 1
sec to clear.
SYSTEM LO All
Records the lowest supply temperature. Press UP/DOWN for 1
sec to clear.
IND HI
H MODE 1,2,3
Records the highest Indirect supply temperature. Press
UP/DOWN for 1 sec to clear.
IND LO
H MODE 1,2,3
Records the lowest Indirect supply temperature. Press
UP/DOWN for 1 sec to clear.
TANK HI WH
Records the highest Tank temperature. Press UP/DOWN for 1
sec to clear.
TANK LO WH
Records the lowest Tank temperature. Press UP/DOWN for 1
sec to clear.
POOL HI P
Records the highest pool temperature. Press UP/DOWN for 1 sec
to clear.
POOL LO P
Records the lowest pool temperature. Press UP/DOWN for 1 sec
to clear.
