Raypak 336A Installation And Operation Manual

51
CALL OUT 206A 266/266A 336A 399/406A
P
1-P Pilot Nat. MV 600525B 600525B 600525B 600525B
Pilot Pro. MV 600575B 600575B 600575B 600575B
3-P Pilot Orifice Nat. MV 003901F 003901F 003901F 003901F
Pilot Orifice Pro. MV 003902F 003902F 003902F 003902F
5-P Pilot Generator MV 600019B 600019B 600019B 600019B
2-P Pilot Nat & Pro IID 002003F 002003F 002003F 002003F
4-P Pilot Orifice Nat. IID .020 003903F 003903F 003903F 003903F
Pilot Orifice Pro. IID .012 004308F 004308F 004308F 004308F
6-P Pilot MTG Bracket MV 010352F 010352F 010352F 010352F
7-P Pilot Mounting Bracket IID 306692 306692 306692 306692
8-P Lighter Tube (MV Units Only) 062996 062996 062996 062996
9-P Pilot Tube 004078F 004078F 004078F 004078F
10-P Hi Tension Wire IID with Pilot Electrode N/A N/A N/A N/A
11-P Pilot Shield 010351F 010351F 010351F 010351F
R
1-R Refractory Common Lt & Rt 010088F 010088F 010088F 010088F
2-R Refractory Uncommon (Front & Rear) 010089F 010090F 010091F 010092F
3-R Refractory Retainer Kit 010387F 010388F 010389F 010390F
S
1-S Jacket Top (Louvered) 010047F 010048F 010049F 010050F
2-S Flue Collector (Units with Polymer Header) 010071F 010072F 010073F 010074F
Flue Collector (Units with Metal Header) 010075F 010076F 010077F 010078F
3-S Door Assy
Raypak
Cool Dark & Warm Dark Gray 013859F 013860F 013861F 013862F
Green 010378F 010379F 010380F 010381F
Rheem
Cool Dark & Warm Dark Gray 013863F 013864F 013865F 013866F
Green 010382F 010383F 010384F 010385F
Ruud
Cool Dark & Warm Dark Gray (Units mfd after 9/2012) 013859F 013860F 013861F 013862F
Warm Dark Gray (Units manufactured prior to 9/2012) 013867F 013868F 013869F 013870F
Green 010382F 010383F 010384F 010385F
Jacuzzi N/A 016698F N/A 016699F
14-S Screw & Retainer 006744F 006744F 006744F 006744F
4-S Access Panel Set (3 Pcs Units with Polymer Header) 010311F 010311F 010311F 010311F
Access Panel Set - ASME
Access Panel Set (3 Pcs. for BR Header) - from 12/2019 017967F 017967F 017967F 017967F
Access Panel Set (3 Pcs. for CI Header) - prior to 12/2019 010312F 010312F 010312F 010312F
5-S Jacket Side Panel Right 010376F 010376F 010376F 010376F
6-S Jacket Side Panel Left 010377F 010377F 010377F 010377F
7-S Jacket Rear Panel (2 Pcs.) 010372F 010373F 010374F 010375F
8-S Poolstat Cover/Lock 009505 009505 009505 009505
9-S High Limit Cover - prior to 12/2019 010319F 010319F 010319F 010319F
10-S Base Heat Shield - prior to 10/2019 010320F 010320F 010320F 010320F
11-S Up Front Control Panel
Green 010321F 010322F 010323F 010324F
Cool Dark Gray 013887F 013888F 013889F 013890F
Warm Dark Gray 013891F 013892F 013893F 013894F
12-S High Limit Shield 010342F 010342F 010342F 010342F
13-S Weather Shield 010325F 010326F 010327F 010328F
V
1-V Indoor Stack Kit (Includes inner adapter panel) 009838 009839 009840 009841
Outdoor Stack Kit (Includes inner adapter panel) 009834 009835 009836 009837
2-V Stack Adapter 010330F 010331F 010332F 010333F
4-V Outer Stack Adapter 011461F 011462F 011463F 011464F
3-V "Pagoda" Top
Cool Dark Gray 013883F 013884F 013885F 013886F
Green 010334 010335 010336 010337
Atmospheric CONVERSION KITS*
Gas Conversions
Nat. to Pro. MV Pilot 004690B 004690B 004692B 004692B
Pro. to Nat. MV Pilot 010419F 010419F 010420F 010420F
Nat. to Pro. IID Pilot ** ** ** **
Pro. to Nat. IID Pilot ** ** ** **
VENTING
DESCRIPTION
* Gas conversions are to be done only by a qualified agency.
** Conversion must be made with complete burner tray and gas valve (see item 1-B).
PILOT
REFRACTORY
SHEET METAL
PRELIMINARY
UNCONTROLLED DOCUMENT IF PRINTED
