Table E: INSTALLER/SERVICE MENU — POWER DEFROST Configuration
Item Range
Default
Value
Access Level Description
Set Current
Time
12:00A–11:59P --- Installer
Selects current time – “A” or “P” will
indicate whether the set time is AM
or PM.
Pump Periods 0–4 Installer
Only available if Pump Operation
in the Installer’s Menu is set to
“4-Speed Enabled” or “Variable
Enabled”.
Pump On Time 1
12:00A–11:59P --- Installer
Select ON time for Pump Period #1 to
take effect.
Pump Off Time 1 12:00A–11:59P --- Installer
Select OFF time for Pump Period #1
to stop.
Pump Speed 1
1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer
On 4-speed pumps, this denotes the
selected pump output (which connects
to the pump for the selected speed)
for this pump period. On Variable
speed pumps, this denotes the PWM
signal to be provided to the pump for
pump operation.
Return Valve 1
Pool/Spa Pool Installer
Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 1 Pool/Spa Pool Installer
Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 2 12:00A–11:59P --- Installer
Select ON time for Pump Period #2 to
take effect.
Pump Off Time 2 12:00A–11:59P --- Installer
Select OFF time for Pump Period #2
to stop.
Pump Speed 2
1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer
On 4-speed pumps, this denotes the
selected pump output (which connects
to the pump for the selected speed)
for this pump period. On Variable
speed pumps, this denotes the PWM
signal to be provided to the pump for
pump operation
Return Valve 2 Pool/Spa Pool Installer
Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 2 Pool/Spa Pool Installer
Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 3 12:00A–11:59P --- Installer
Select ON time for Pump Period #3 to
take effect.
