28
Item Range
Default
Value
Access Level Description
AUX1 On Time 12:00A-11:59P ---
Installer/
Service Sub-menu
Select ON time for AUX1 to take effect.
AUX1 Off Time 12:00A-11:59P ---
Installer/
Service Sub-menu
Select OFF time for AUX1 to stop.
AUX2 On Time 12:00A-11:59P ---
Installer/
Service Sub-menu
Select ON time for AUX2 to take effect.
AUX2 Off Time 12:00A-11:59P ---
Installer/
Service Sub-menu
Select OFF time for AUX2 to stop.
Cooling Deadband
2°F–10°F
(1°C–5.5°C)
6°F
(3.3°C)
Installer/
Service Sub-menu
In Pool Auto mode, the cooling setpoint
is the heating setpoint minus this Cooling
Deadband value.
Defrost Temp
20°F–35°F
(-6.5°C–1.5°C)
35°F
(1.5°C)
Installer/
Service Sub-menu
This is the temperature measured on the
coil when the control goes into Defrost
mode.
Def Terminate
40°F–60°F
(4°C–15.5°C)
50°F
(10°C)
Installer/
Service Sub-menu
If the coil temperature reaches this setpoint,
Defrost will terminate. Other Defrost
algorithms are still operating behinds the
scene.
Outside Lockout
Off,
30°F–50°F
(-1°C–10°C)
Off
Installer/
Service Sub-menu
The installer can program the control
to Lock out operation of the unit if a
specific outside temperature is measured.
Off allows operation at any ambient
temperature.
Set Model Type
HEAT ONLY,
POWER DEFROST,
HEAT/COOL
HEAT/
COOL
Installer/
Service Sub-menu
Set at the factory. Will need to be set by
Installer during any replacement of the
control board.
EXV
Disabled, Type 1,
Type 2
Disabled
Installer/
Service Sub-menu
Set at the factory on new units. Select
“Disabled” if unit equipped with TXV for
board replacement. EXV Type 1 is 500
step EXV. EXV Type 2 is 1600 step EXV.
Change EXV to Yes/No
Installer/
Service Sub-menu
This screen asks if you really want to
change the EXV setting – the UP or DOWN
button must be pressed to show YES
before the EXV type will be changed.
Brownout
Detection On
On/Off On
Installer/
Service Sub-menu
This function will shut down operation of the
unit if the 24VAC signal drops below 18VAC
to protect the unit from Low Voltage. This
feature can be turned off as desired.
Set Factory
Defaults
Installer/
Service Sub-menu
Press and hold both the UP and DOWN
buttons for 3+ seconds to reset the factory
defaults in the control. When reset, the
screen will display “Defaults Set”.
NOTE: Make sure that the values for each setting are recorded for future reference or if the control ever needs
to be reset to Factory Defaults. All these values will need to be re-entered.
