16
Item Range
Default
Value
Access Level Description
Return Valve 2 Pool/Spa Pool User Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 2 Pool/Spa Pool User Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 3 12:00A–11:59P --- User
Select ON time for Pump Period #3 to
take effect.
Pump Off Time 3
12:00A–11:59P --- User
Select OFF time for Pump Period #3
to stop.
Pump Speed 3
1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User
On 4-speed pumps, this denotes the
selected pump output (which connects
to the pump for the selected speed)
for this pump period. On Variable
speed pumps, this denotes the PWM
signal to be provided to the pump for
pump operation.
Return Valve 3 Pool/Spa Pool User
Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 3
PoolSpa Pool User
Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 4 12:00A–11:59P --- User
Select ON time for Pump Period #4 to
take effect.
Pump Off Time 4 12:00A–11:59P --- User
Select OFF time for Pump Period #4
to stop.
Pump Speed 4
1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User
On 4-speed pumps, this denotes the
selected pump output (which connects
to the pump for the selected speed)
for this pump period. On Variable
speed pumps, this denotes the PWM
signal to be provided to the pump for
pump operation.
Return Valve 4 Pool/Spa Pool User
Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 4 Pool/Spa Pool User
Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
NOTE: Make sure that the values for each setting are recorded for future reference or if the control ever needs
to be reset to Factory Defaults. All these values will need to be re-entered.
