Raypak 8450 Series User Manual

15
Control Settings
Item Range
Default
Value
Access Level Description
Set Current
Time
12:00A–11:59P --- User
Selects current time – “A” or “P” will
indicate whether the set time is AM
or PM.
C/F Display Celsius/Fahrenheit Fahrenheit User
Selects the units of measure for
temperature readings.
Spa Max Temp
65°F–104°F
(18°C–40°C)
104°F
(40°C)
User
Selects the maximum Spa
temperature that the control can be
adjusted to in normal operation.
Pool Max Temp
65°F–95°F
(18°C–35°C)
95°F
(35°C)
User
Selects the maximum Pool
temperature that the control can be
adjusted to in normal operation.
Pump Periods 0–4 User
Only available if Pump Operation
in the Installer’s Menu is set to
“4-Speed Enabled” or “Variable
Enabled”.
Pump On Time 1
12:00A–11:59P --- User
Select ON time for Pump Period #1 to
take effect.
Pump Off Time 1
12:00A–11:59P --- User
Select OFF time for Pump Period #1
to stop.
Pump Speed 1 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User
On 4-speed pumps, this denotes the
selected pump output (which connects
to the pump for the selected speed)
for this pump period. On Variable
speed pumps, this denotes the PWM
signal to be provided to the pump for
pump operation.
Return Valve 1 Pool/Spa Pool User
Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 1 Pool/Spa Pool User
Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 2 12:00A–11:59P --- User
Select ON time for Pump Period #2 to
take effect.
Pump Off Time 2 12:00A–11:59P --- User
Select OFF time for Pump Period #2
to stop.
Pump Speed 2
1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User
On 4-speed pumps, this denotes the
selected pump output (which connects
to the pump for the selected speed)
for this pump period. On Variable
speed pumps, this denotes the PWM
signal to be provided to the pump for
pump operation.
Table C: USER MENU — Heat ONLY, Power Defrost and Heat/Cool Models
NOTE: The User Menu is exactly the same for Heat
ONLY, Power Defrost and Heat/Cool models.
