Table Q: Temperature Control Default Setpoints—Boiler
Boiler (H7)
Item Modes Default Setting Range
B
oil Target
2 1
40°F
O
FF, 70 to 220°F
3 1
60°F
O
FF, 70 to 190°F
5, 7 180°F OFF, 70 to 220°F
Boil Max
2, 5, 7, 8 200°F OFF, 120 to 225°F
3 180°F OFF, 120 to 190°F
Boil Min 2, 3, 5, 7 135°F OFF, 80 to 180°F
‘Burner’ Delay All 0:00 min 0:00 to 3:00 min
Boil Mass All 1 (Low) 1 (Low), 2 (Med), 3 (High)
Diff 2, 3, 5, 7 Auto Auto, 2 to 42°F
DHW Target 3 120°F OFF, 70 to 190°F
DHW Diff 3 5°F 2 to 10°F
‘Pump’ Dly All 3:00 min OFF, 0:20 to 9:55 min, ON
Outdr Start 5 70°F 35 to 85°F
Outdr Design 5 -10°F -60 to 32°F
Boil Start 5 135°F 35 to 150°F
Boil Dsgn 5 180°F 120 to 220°F
WWSD 5 70°F 35 to 100°F
Units All °F °F or °C
Mode N/A 2 2, 3, 5, 7, 8
External Input Signal 7 2 to 10 VDC 2 to 10 VDC or 0 to 10 VDC
Offset 7 0°F -10°F to 10°F
Pool Heater (P, WHP)
Item Modes Default Setting Range
Boil Target 2 78°F OFF, 45 to 106°F
Boil Max 2 86°F OFF, 70 to 106°F
Boil Min 2 70°F OFF, 45 to 106°F
‘Burner’ Delay All 0:00 min 0:00 to 3:00 min
Boil Mass All 1 (Low) 1 (Low), 2 (Med), 3 (High)
Diff 2 1°F 1 to 3°F
‘Pump’ Dly All 3:00 min OFF, 0:20 to 9:55 min, ON
Units All °F °F or °C
Mode N/A 2 2
Table R: Temperature Control Default Setpoints—Pool Heater
