Page 5 of 32
INSTALLATION INSTRUCTIONS
Warning: This appliance must be installed in accordance with all local state and federal laws including the regulations of any
government bodies and in complete accordance with these instructions. Where these instructions are contrary to the law or
regulations of an appropriate government body those laws or regulations should take precedence subject to there being no
compromise to safety.
BEFORE YOU COMMENCE INSTALLATION
1. Read these instructions in full.
2. Check that the pool or spa heater you have been supplied is suitable for the gas type that is available.
3. Ensure that your gas fitter checks that the gas supply pressure is between the minimum and maximum specified on the heater
data plate.
4. Confirm that the heater you have purchased is suitable for the location it is to be installed, i.e. Outdoor or Indoor.
5. Check that your pool system pump will provide water flow between the specified minimum and maximum flow rates required for
the heater to operate.
6. Remove packaging and timber base before installation.
7. Complete all details on the back page of this book.
PRODUCT APPLICATIONS
Raypak “Residential” pool & spa heaters are designed and built for installation in applications where the intention of its use is to heat
a pool or spa of a single family dwelling. Its use in an application other than this may shorten its life. Residential heaters are not
intended for installation in commercial applications such as multi residential apartments. For these applications a Raypak
“Commercial” pool or spa heater (also referred to as “Premium”) pool or spa heater should be selected.
See WARRANTY & SERVICE section in this book for details of the different Rheem warranties dependent on the heater type and
its intended application.
HEATER LOCATION
The heater must be located so that any possible water leaks will not damage adjacent areas or structures. When such locations
cannot be avoided it is recommended that a suitable safe tray be constructed and installed by your plumber. This must not restrict
air required for combustion.
The heater must be located on a level non-combustible surface such as concrete. All packaging must be removed before installation.
OUTDOOR HEATERS
Raypak pool & spa heaters are built for outdoor installations as standard. The installation must conform to AS5601 OR AS/NZS
5601.1 as a minimum. They must not be installed in any enclosed structure or under eaves, roof overhangs, or pool decks. Outdoor
pool & spa heaters must be installed at least 1500mm from any window or room ventilation opening. They must also have no
obstructions above the appliance.
If installing the heater on a raised base, the base must be non-combustible and contain no air openings or perforations. Drafts from
below the heater can affect its operation.
High Wind Areas
Raypak pool & spa heaters are atmospherically vented and so may not function correctly in areas of sudden changing air pressure
often caused by high or variable wind speeds. In some instances, it may be necessary to install either a Raypak High Wind Top or
a Raypak Induced Draft Fan to ensure correct operation. These options should be discussed with Rheem before installation.
In areas of "constant extreme winds" or in areas where high winds frequently occur, it is necessary to locate the heater a minimum
of one (1) metre from high vertical walls, or install a wind break so that the heater is not positioned and exposed in the direction of
the prevailing winds.
INDOOR HEATERS
Combustion / Ventilation Air
Indoor pool & spa heaters must only be installed in a protective enclosure or properly constructed room, with ventilation in accordance
with AS5601 OR AS/NZS 5601.1. Ventilation must be provided via two permanent openings, one at ceiling level and one at floor
level. Minimum vent area must be in accordance with AS5601 OR AS/NZS 5601.1. Minimum opening dimensions in the vent must
be at least 6mm.
For indoor applications the pool or spa heater must have at least the minimum clearances specified in the table below on page 6.
Increased clearances should be provided where possible to improve serviceability. If the pool or spa heater is not installed in
accordance with the sufficient and safe space for ease of service around the unit, Rheem advises that the pool or spa heater will be
disconnected and removed to enable servicing.
