Page #30 background image
Installation
30 Rev. E3 07/2013 MP150
Current Outputs, 4-pin
Description
Color (6 wires)
1
IGND
common ground connection for all current outputs, electrically isolated to the GND
ground
brown, pink, gray
2
OUT1
current output 1
yellow
3
OUT2
current output 2
green
4
OUT3
current output 3
white
shield
black
Power Supply 24 V, 3-pin
Description
Color (6 wires)
1
GND
power ground
brown
2
not connected
3
+ 24 VDC
input for + 24 VDC power supply voltage
white
shield
black
RS485 Interface, 7-pin
Description
Color (6 wires)
1
GND
Ground, (connected to power ground)
gray
2
T+
RS485 transmit
brown
3
T-
RS485 transmit
white
4
R+
RS485 receive
green
5
R-
RS485 receive
yellow
6
n.c.
7
+ 12 VDC
regulated voltage for the RS232/485 converter
pink
shield
Alarm, Trigger, 6-pin
Description
Color (6 wires)
1
Relay contact
Potential free relay contact, capacity max. 30 V, 1 A.
brown
2
Relay contact
Potential free relay contact, capacity max. 30 V, 1 A
white
3
Trigger +
Trigger input: + 5 to + 24 VDC
green
4
Trigger -
Trigger input GND
yellow
5
Functional input
max. + 5 VDC
pink
6
Functional input
GND
gray
shield
black
