ELECTRIC SCOOTER PARTS
1. Handlebar Grip Plug (Left/Right)
2. Handlebar Grip (Left/Right)
3. Thumb Throttle
4. Brake Lever Assembly
5. T-Bar
6. Collar Clamp
7. Headset (Upper/Lower)
8. Front Fork with Limiter
9. Front Caliper Brake with Brake Pads
10. Front Wheel Complete
11. Kickstand
12. Rear Wheel with Hub Motor Complete
13. Rear Fender
14. Deck
15. Battery Dock Cover (Left/Right)
16. On/Off Switch
17. Kobalt 24V Max Battery (24V/2Ah)
18. Control Module
Keep your electric scooter running for years with genuine Razor parts. Visit our website or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
