BEFORE YOU BEGIN
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during
shipping. Because the scooter was 95 percent assembled and packed at the factory, there should not be any
problems, even if the box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult.
Allow up to 10 minutes for assembly, not including initial charge time.
Allow up to 85 minutes for charge (see page 5 for charging information).
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR RAZOR
ELECTRIC SCOOTER. The scooter
has been built to certain Razor
design specifications. The original
equipment supplied at the time of
sale was selected on the basis of its
compatibility with the frame, fork and
all other parts. Certain aftermarket
products may not be compatible and
will void the warranty.
Required Tool
5 mm Allen Wrench
Product ID Locations:
(See locations to the left)
1. Handlebar Stem
2. Bottom of Frame
3. UPC side of box (not shown)
4. Charger
Box Contents:
• Electric Scooter
• Kobalt 24V Max Battery
• Kobalt 24V Max Charger
• Allen Wrench
• Electric Scooter Owner’s Manual
• Kobalt 24V Max Battery
Owner’s Manual
• Kobalt 24V Max Charger
Owner’s Manual
Note: Electric scooter must be
moving at least 3 mph (5km/h)
while applying throttle to
engage motor.
1.
4.
Thumb Throttle
Brake Lever
ON/OFF Switch
Kobalt 24V Max Battery
Control Module
Kickstand
Hub Motor
Limiter
Kobalt 24V Max Charger
(Note: Charger design may
vary from one shown)
2.
