58
2 Rigging the TWS Lumbar Strap
a Remove the BAT wing if fitted to the Razor Harness.
b Bolt the top of the Lumbar Strap webbing to the bottom hole of the DSP using one
of the supplied button head screws and a washer.
c If the BAT Wing is also normally attached at this bottom hole on the DSP then the
longer bolt found in the BAT Wing or Universal Spares kit will be required to fix
both the Lumbar Strap and the BAT Wing to the same mounting point.
d Slide block weights onto the webbing and position them correctly on the Lumbar
strap between the DSP and the MBP to optimize trim. Ideally weight should not be
placed above the Lumbar Strap Tri-glide so as not to interfere with the SM Bungee.
e Up to 4 block weights can be added to the Lumbar Strap. If more head down trim
is required the weight can be moved closer to the DSP or the heavier weights can
placed at the top of the Lumbar Strap. If more head up trim is required weight can
be moved closer to the MBP or the heavier blocks placed lower on the Lumbar
Strap.
f Feed the free end of the webbing through the top slot of the MBP (the top slot “A”
on the MBP is cut slightly wider than the other slots to accept the Lumbar Strap
easily) and double the webbing back over.
