3 Rigging the TWS Waist Strap
a Remove the BAT wing if fitted to the Razor Harness.
b Slide the Waist Strap of the TWS under the webbing of the Razor Harness that
passes through slots A and B of the MBP and bolt it into the hole in the middle of
the MBP using one of the supplied button head screws and a washer.
c Slide one block weight onto either side of the Waist Strap webbing. Up to a maxi-
mum of 3kgs can be used on either side. The amount of weight used should be
equal either side.
d Bolt the outside grommets into the DAPs on either side using 2 of the button head
screws and washers supplied. With small weight blocks use the two inside grom-
mets and with large block weights use the 2 outside grommets.
e The DAPs can be moved on the Razor Harness either closer to or further away from
the MBP as required to get a good fit with the Waist Strap of the TWS.
f Neoprene Wraps are not required for the Waist Strap
g Double check all fittings on the TWS are secure and refit the BAT Wing.
