RBI FlexCore CK 3000 User Manual

MODBUS COMMUNICATIONS HeatNet Control V3
Page 121
MODBUS Input Variables (Read Only)
Address
Name
Raw Data
Type
Scale
Description
Valid Values/Range
30049
Boiler01RuntimeLow16
Boiler (1 – 16) Runtime seconds High
(Upper) and Low (Lower) 16 bit
counters. To get the actual runtime for
any given boiler (##), the high and low
16 bit counters must be combined
(concatenated) into a single 32 bit
counter as:
Boiler##RuntimeHigh16:Boiler##Runti
meLow16
Example
Boiler01Runtime =
(Boiler01RuntimeHigh16 * 65536) +
Boiler01RuntimeLow16
Boiler01 = Master
Boiler02 = Member01
…
Boiler16 = Member15
30050
Boiler02RuntimeHigh16
30051
Boiler02RuntimeLow16
30052
Boiler03RuntimeHigh16
30053
Boiler03RuntimeLow16
30054
Boiler04RuntimeHigh16
30055
Boiler04RuntimeLow16
30056
Boiler05RuntimeHigh16
30057
Boiler05RuntimeLow16
30058
Boiler06RuntimeHigh16
30059
Boiler06RuntimeLow16
30060
Boiler07RuntimeHigh16
30061
Boiler07RuntimeLow16
30062
Boiler08RuntimeHigh16
30063
Boiler08RuntimeLow16
30064
Boiler09RuntimeHigh16
30065
Boiler09RuntimeLow16
30066
Boiler10RuntimeHigh16
30067
Boiler10RuntimeLow16
30068
Boiler11RuntimeHigh16
30069
Boiler11RuntimeLow16
30070
Boiler12RuntimeHigh16
30071
Boiler12RuntimeLow16
30072
Boiler13RuntimeHigh16
30073
Boiler13RuntimeLow16
30074
Boiler14RuntimeHigh16
30075
Boiler14RuntimeLow16
30076
Boiler15RuntimeHigh16
30077
Boiler15RuntimeLow16
30078
Boiler16RuntimeHigh16
30079
Boiler16RuntimeLow16
30080
Boiler01Status3
16 bit unsigned
---
Boiler (1 – 16) stage control input
flags. These bits indicate the state of
the stage control inputs. See the
values column for a list of conditions.
See the “BoilerStatus3”
Table below.
30081
Boiler02Status3
30082
Boiler03Status3
30083
Boiler04Status3
30084
Boiler05Status3
30085
Boiler06Status3
30086
Boiler07Status3
30087
Boiler08Status3
