RBI FlexCore CK 3000 User Manual

MODBUS COMMUNICATIONS HeatNet Control V3
Page 123
MODBUS Input Variables (Read Only)
Address
Name
Raw Data
Type
Scale
Description
Valid Values/Range
30126
Boiler15ReturnTemp
30127
Boiler16ReturnTemp
30128
Boiler01CyclesHigh16
16 bit unsigned
---
Boiler (1 – 16) Cycles High (Upper)
and Low (Lower) 16 bit counters. To
get the actual cycle count for any
given boiler (##), the high and low 16
bit counters must be combined
(concatenated) into a single 32 bit
counter as:
Boiler##CyclesHigh16:Boiler##Cycles
Low16
Example
Boiler01Cycles =
(Boiler01CyclesHigh16 * 65536) +
Boiler01CyclesLow16
Boiler01 = Master
Boiler02 = Member01
…
Boiler16 = Member15
0 – 4294967295
30129
Boiler01CyclesLow16
30130
Boiler02CyclesHigh16
30131
Boiler02CyclesLow16
30132
Boiler03CyclesHigh16
30133
Boiler03CyclesLow16
30134
Boiler04CyclesHigh16
30135
Boiler04CyclesLow16
30136
Boiler05CyclesHigh16
30137
Boiler05CyclesLow16
30138
Boiler06CyclesHigh16
30139
Boiler06CyclesLow16
30140
Boiler07CyclesHigh16
30141
Boiler07CyclesLow16
30142
Boiler08CyclesHigh16
30143
Boiler08CyclesLow16
30144
Boiler09CyclesHigh16
30145
Boiler09CyclesLow16
30146
Boiler10CyclesHigh16
30147
Boiler10CyclesLow16
30148
Boiler11CyclesHigh16
30149
Boiler11CyclesLow16
30150
Boiler12CyclesHigh16
30151
Boiler12CyclesLow16
30152
Boiler13CyclesHigh16
30153
Boiler13CyclesLow16
30154
Boiler14CyclesHigh16
30155
Boiler14CyclesLow16
30156
Boiler15CyclesHigh16
30157
Boiler15CyclesLow16
30158
Boiler16CyclesHigh16
30159
Boiler16CyclesLow16
30160
Boiler01Status4
16 bit unsigned
---
Boiler (1 – 16) status4 flags. These bits
indicate the state of various boiler statuses.
Boiler01 = Master or “Connected Boiler”
Boiler02 = Member01
…
Boiler16 = Member15
See the BoilerStatus4
Flags in Appendix A.
30161
Boiler02Status4
30162
Boiler03Status4
30163
Boiler04Status4
30164
Boiler05Status4
