OPTIONAL FEATURES HeatNet Control V3
Page 66
This screen is an excellent way to diagnose system
problems and tune systems for optimal performance.
Data Points can also be viewed in a manner other than a
histogram as pictured below. The date/time picker can be
used to mine the raw data stored on the HeatNet Online
server.
Runtime graphs of each boiler ensure even runtimes are
being observed by a properly operating system.
This is just an overview of HeatNet Online and a few of
the screens that are available.
Wiring Connections
Figure 48 Dip Switches and Wiring
Wire Strip Length.
If the terminal blocks are of the screwless type, the wire should be stripped to .42” or 10.67mm.
If the terminal blocks are of the screw type, the wire should be stripped to .25” or 6.34mm.
