RBI infinite energy 2 User Manual

34
Figure 6-1 Remove heater from wood pallet
C
B
A
020010.01.011
D
020010.01.012
Figure 6-2 Remove heater from wood pallet
6.1 - Transporting
the heater
WARNING!!!
Always lift
and carry the heater with a hand
truck or special equipment.
Failure to comply with this
provisions could result in
severe personal injury, death or
substantial property damage.
CAUTION!!!
The heater may be
damaged when it is improperly
secured and transported.
CAUTION!!!
The unpacked
heater may be damaged
when not protected against
contamination
 Only transport the heater using the
right transportation equipment, such
as a hand truck with a fastening
belt or special equipment for
maneuvering steps.
 During transportation the
heater must be secured on the
transportation equipment to prevent
it from falling off.
 Protect all parts against impacts if
they are to be transported.
 Leave the protective covers on the
connections.
 During transportation, cover the fl ue
gas and air intake connections at the
top of the heater with plastic fi lm
6.2 - Mounting the
heater
1. Remove the outer shipping carton
from the heater .
2. Remove the front door (see Section
15.2) to access the screw “C”
(Figure 6-1) in front of the unit
3. Remove the screw “D” in the rear of
the unit (Figure 6-2).
6 - INSTALLATION - Mounting the heater
