Eagle - Onboard air-data measuring system for R/C planes. Page 3
Introduction
The “Eagle” is one component of RC Electronics model aircraft telemetry system. The unit is designed to
measure many parameters of an R/C model aircraft and transmit them to the ground via the primary
system telemetry back link. The unit is capable of measuring sink/climb rate (Vario), altitude, acceleration
of the plane in all axes, noise level, servo pulse on servo input, GPS data with 18Hz refresh rate and supply
voltage. For storage it has internal fast solid state storage which is will record up to last 20h of flying.
Key features of the Eagle
• Integrated fast solid state memory for up to 20h of logging
• Latest pressure sensor for ultra fast detection of climb / sink
• Two pressure sensors for altitude and Vario measuring
• 3 axes accelerometer
• Enl - Environment noise level detection to detect working electric, impeller or jet motor.
• 18 Hz GPS working with GNSS, Glonass and prepared for Galileo global positioning satellites.
• Various telemetry protocol supported over one of servo input (JetiEx, PowerBox System, Hott ...)
Specifications
1
Specifications are taken from component ratings and system limits and may not have been tested to the
full extent of the specified ranges.
