Connecting AV Composite device (Good Video Quality)
To connect a composite AV device, such as a DVD player, follow these steps:
1. Connect the Video In jack on the back of TV to the video output
jacks of device via video cable (yellow).
2. Connect the AUDIO IN R-AUDIO-L jacks on the back of TV to the a
udio output jacks of device via audio cable.
Notice the left channel jack and plugs are white and the right channel jack and plugs are red.
Composite Video Connection
The picture below is an example of a connection using the composite video jack.
Note: AV signal belongs to composite video. This kind of video signal has regular good display quality.
The back of TV
Audio
L R
Audio
L R
Video
YPbPr
HDMI
The output panel of other device
13
Back Panel Connections
