The back of TV
Connecting a computer
To connect a computer, follow these steps:
1. Connect the PC INPUT VGA port on the back of TV to the VGA outp
ut jack of device via D-sub 15-pin cable.
2. Connect the SOUND/DVI jack on the back of TV to the audio outpu
t jack of computer with audio cable (3.5mm).
PC Connection
The picture below is an example of a connection using your TV as a PC monitor.
Note: If you want to use your TV as a monitor, please notice that the maximum resolution for 42PA30RQ is 1024*768.
Please set the computer graphic correctly.
VGA
Speaker or
headphone
PC
16
Back Panel Connections
How to Obtain Various Kinds of Input Sources
After connection is done, press INPUT button on remote control or TV top panel to choose the input source you need.
See page 22, Basic Operation of TV.
