RCA ANT705Z

2
Assembling the antenna
1. Attach the reectors to the antenna boom.
Pieces used in this step:
(3) M6x30 carriage bolts
(1) Antenna boom (2) Reectors (2) Reector clamps (3) M6 small wing nuts
A. Place the two reector clamps on either side of the large hole on the antenna boom.
B. Insert the reectors into the clamps and tighten the clamps.
Turn the boom around. Place one of the
reectors in the top part of the clamp as
shown.
Place one of the M6x30 carriage bolts
through the clamps and reector as
shown. Screw a wing nut onto the other
side of the bolt (but don’t tighten it all the
way yet).
Place the other reector into the bottom
of the clamp. Place one of the M6x30
carriage bolts through the clamps and
reector as shown. Screw a wing nut
onto the other side of the bolt.
Tighten all the wing nuts.
Line up the middle hole on each clamp
with the hole on the boom.
Place one of the M6x30 carriage bolts
through the clamps and boom as shown.
Screw a wing nut onto the other side of
the bolt (but don’t tighten it all the way
yet).
Bolt
Clamps
Hole
