14
Copyright © 2022 RCA Communications Systems www.RCACommunicationsSystems.com
Communications Systems
RDR23x0 Professional Digital
Two-Way Radios
INSTRUCTION MANUAL
RCA and the RCA logo are trademarks of Technicolor SA and are used under license. All other trademarks are the property of their respective owners. © 2022 RCA Communications Systems. All rights reserved.
www.rcacommunicationssystems.com
products@rcacommunicationssystems.com
(877) 822-2915
Created in U.S.A.
Communications Systems
Turning the Radio Tones/Alert On/O
You can enable and disable all radio tones and alerts (except for the
incoming Emergency alert tone) if needed. Press the programmed All
Tones/Alerts button to toggle all tones on or o. OR (RDR2390 Only) -
1. Press [O] to access the main menu.
2. Press [<] or [>] to navigate to Utilities and press [O] to select.
3. Press [<] or [>] to navigate to Radio Settings and press [O] to select.
4. Press [<] or [>] to navigate to Tones / Alerts and press [O] to select.
5. Press [<] or [>] to navigate to All Tones and press [O] to select.
6. If the display shows Turn On press [O] to enable all tones and alerts
and the display shows All Tones On. If the display shows Turn O
press [O] to disable all tones and alerts and the display shows All
Tones O.
Turning the LED Indicator On/O (RDR2390 Only)
You can enable and disable the LED Indicator if needed.
1. Press [O] to access the main menu.
2. Press [<] or [>] to navigate to Utilities and press [O] to select.
3. Press [<] or [>] to navigate to Radio Settings and press [O] to select.
4. Press [<] or [>] to navigate to LED Indicator and press [O] button.
5. If the display shows Turn On, press [O] to enable the LED Indicator
and the display shows All LEDs On. If the display shows Turn O,
press [O] to disable the LED Indicator and the display shows All LEDs
O.
Note: The display backlight, buttons and keypad backlight are
automatically turned o if the LED indicator is disabled.
Turning the Introduction Screen On/O (RDR2390 Only)
You can enable and disable the Introduction Screen if needed.
1. Press [O] to access the main menu.
2. Press [<] or [>] to navigate to Utilities and press [O] to select.
3. Press [<] or [>] to navigate to Radio Settings and press [O] to select.
4. Press [<] or [>] to navigate to Intro Screen and press [O] to select.
5. If The display shows Turn On, press [O]
to enable the Introduction Screen and the display shows Intro
Screen On. If the display shows Turn O, press [O] to disable the
Introduction Screen and the display shows Intro Screen O.
Accessing General Radio Information (RDR2390 Only)
Your radio contains information on the following:
• Radio ID
• Software version
• Codeplug Version
Checking the Radio ID
1. Press [O] to access the main menu.
2. Press [<] or [>] to navigate to Utilities and press [O] to select.
3. Press [<] or [>] to navigate to Radio Info and press [O] to select.
4. Press [<] or [>] to navigate to My Number, or Firmware Vr., or CP Vr.
and press [O] button.
5. The display shows radio ID, the current firmware or the codeplug
version.
CARE AND CLEANING
• Do not directly handle the radio by its antenna or external
microphone. Damage due to improper handling and misuse is NOT
covered under the warranty.
• Do not place the radio in a dusty or dirty environment.
• Clean the radio with a lint-free cloth moistened with clean water
and/or a mild dishwashing liquid to remove dirt, grease and dust.
• Avoid exposing the radio to corrosives, solvents, or spirits.
• Avoid exposing the radio and it’s battery to direct sunlight for
prolonged periods of time.
Symptom Solution
Radio will not power on
a. The battery needs charging.
Recharge the battery or replace it
with a fresh one.
b. The battery is not properly
installed. Remove the battery and
reattach it.
The operating time is
noticeably shorter than
normal even though the
battery is properly charged.
a.
The battery has worn out; it is time
to buy a new battery.
b.
The battery is not fully charged.
Make sure that the battery is
removed after LED indicator has
turned green.
Cannot talk to or hear
transmissions from your
group members
a. Make sure that your radio operates
on the same channel and / or has
the same CTCSS/CDCSS settings
as your group members.
b. Make sure you are within their
communication range.
Radio is on, but you cannot
hear voice transmissions or
they are not very loud
a. Turn the volume control knob to
its maximum volume.
b. Return the radio to your dealer to
check for microphone damage.
TROUBLESHOOTING
