33
RECORDING
Caution:
The unauthorized recording of
satellite broadcasts, television
programs, or other copyrighted
materials may infringe the rights
of others.
CH
VIDEO
AUDIO
ANT. IN
RF OUT
OUT
IN
3
4
PLAYBACK VCR
CABLE BOX
OR ANTENNA
RECORDING VCR
TO TV
TO TV
3 CH. 4
ANT. IN
RF OUT
IN
OUT
OR
OR
VIDEO
UDIO
IN
OUT
Two VCR Connection
Program 1 (One time)
Channel 104 Cable
Start Time 12:00 AM
End Time 01:30 AM
Start Date 12/31/99 FRI
Tape Speed SLP
Press CLEAR to erase
Press MENU for next prog
3. Press CLEAR to erase items or MENU to see the next program.
Using Two VCRs for Copying and
Editing Tapes
Use one VCR as the playback VCR and the other as the
recording VCR.
1. Connect the VCRs using the diagram below.
2. Turn on both VCRs and TV.
3. Tune the TV to the VCR viewing channel (either 3, 4, or
TV’s video input).
4. If you are using coaxial cables for the connection, tune
recording VCR to channel 3 or 4—the one selected on the
playback VCR.
If you are using audio/video cables, select the line input on the
recording VCR.
5. Insert the tape you want to copy into playback VCR. Insert
a blank tape with its safety tab in place into recording VCR.
6. Using visual search, locate the segment you want to copy
on the playback VCR. Pause the tape at this location.
7. Press RECORD on the recording VCR, then PAUSE.
8. Press PAUSE on both VCRs to begin copying.
9. Press PAUSE on both VCRs to stop copying.
10. Repeat steps 6–9 to copy or edit additional segments.
