RCF AM 2080 - Specifications; Amplifier Specifications; Signal to Noise Ratio; Distortion and Tone Controls

26
ENGLISH
SPECIFICATIONS
AMPLIFIER
Output (RMS) power
Frequency response
SIGNAL / NOISE RATIO
- Channels 1, 2
- Aux inputs
Distortion (at 1 kHz, nominal power)
AUX INPUT TONE CONTROLS
- Bass
- Treble
High-pass filter (channels 1, 2)
Input sensitivity / impedance
- Channels 1–2, MIC
- Channels 1–2, LINE
- Aux inputs
‘Phantom power’ voltage / current
LOUDSPEAKER OUTPUTS
Low impedance
Constant voltage
PROTECTIONS
Amplifier
Power supply
GENERIC
Operating voltage
Power (consumption)
Dimensions (w, h, d)
Net weight
80 W
50 Hz ÷ 16 kHz
60 dB
80 dB
< 0.3 %
– 9 ÷ + 6 dB @ 100 Hz
– 14 ÷ + 8 dB @ 10 kHz
150 Hz
Balanced, – 62 dBu (max – 25 dBu ) / 10 kΩ
Balanced, – 29 dBu (max +11 dBu) / 10 kΩ
Adjustable – 18 ÷ + 20 dBu / 20 kΩ
30 V / 18 mA
4 Ω
70 V (63 Ω) / 100 V (125 Ω)
Overload, short circuit, thermal
fuses
115-230V / 50-60 Hz
160 W
442 mm, 88 mm, 230 mm (2U 19” rack)
3.8 kg
